ioBroker.fingerprint

Integrates the ESP32-based FingerprintDoorbell into ioBroker over plain HTTP — no MQTT and no simple-api adapter required.

The adapter runs a small HTTP webhook receiver. The doorbell calls it directly on a fingerprint match or an unknown-finger ring. The adapter also polls the device to report its online/offline status and can reboot it or toggle the touch ring.

Firmware requirement

This adapter talks to the FingerprintDoorbell firmware running on your ESP32.

• Recommended: firmware v0.9.4 or newer — everything below works, including enroll from the adapter, LED-ring control, WiFi signal and reliable multi-finger backup/restore.
• firmware v0.9.3 — reliable backup/restore of all fingers (full 1536-byte templates).
• firmware v0.9.1 — enables server mode (the adapter provisions the device automatically, no manual URLs) plus control.ignoreTouchRing and the fingerprint list.
• firmware v0.9 also works in a basic mode (paste the match/ring URLs manually).

Feature-by-firmware overview:

Get the firmware here:

• Easiest — flash from your browser (fresh ESP32): Web Flasher — connect the ESP32 via USB and click Install (Chrome/Edge/Opera or Firefox 151+).
• Update later via OTA: open http://<device-ip>/update → Firmware → upload firmware.bin from the Releases.
• Manual download: the latest ZIP from the Releases (contains firmware.bin, spiffs.bin and flash instructions).

Check the running version at http://<device-ip>/api/status (field version).

How it works

FingerprintDoorbell (ESP32)                 ioBroker.fingerprint
─────────────────────────                   ────────────────────
match  ──► HTTP GET /match?id=..  ─────────►  webhook receiver ──► lastMatch.*
ring   ──► HTTP GET /ring          ─────────►  webhook receiver ──► ring.*
                                    ◄───────  poll GET /debug   ──► info.connection
reboot                              ◄───────  GET /reboot        ◄── control.reboot
touch ring                          ◄───────  GET /set-touch-ring ◄── control.ignoreTouchRing

Setup

1. Install and add an instance of the adapter.

2. In the instance settings, configure:

   • Device IP Address / Device Port — the doorbell's IP and WebUI port (default 80)
   • Admin User / Admin Password — if HTTP Basic Auth is enabled on the device
   • Webhook Bind IP / Webhook Port — where the adapter listens (default 0.0.0.0:8095)

3. In the FingerprintDoorbell WebUI → Settings, set the HTTP action URLs to point to this adapter (copy the ready-made URLs from the instance settings — they already include the webhook token; replace <iobroker-ip> with the ioBroker host IP):

   HTTP Match URL: http://<iobroker-ip>:8095/match?id={id}&name={name}&confidence={confidence}&token=<token>
   HTTP Ring URL:  http://<iobroker-ip>:8095/ring?token=<token>


Disclaimer

This adapter is an independent, community-made integration. It is not affiliated with, endorsed by or supported by the authors of the FingerprintDoorbell firmware, the sensor manufacturers or ioBroker GmbH. The software is provided "as is", without warranty of any kind (see the MIT LICENSE); you use it at your own risk.

• Not a certified security product. Consumer fingerprint sensors (e.g. R503) can produce false accepts and false rejects and can be spoofed. Do not rely on this adapter as the only protection for doors, locks, alarm systems or anything that guards people or property, and always keep a mechanical or otherwise independent way in and out.
• Not for safety-critical use. Network, Wi-Fi, power or software failures can delay or drop events. Never use it where a failure could endanger life or health (e.g. fire exits).
• Your network, your responsibility. The device WebUI and the webhook use plain HTTP (Basic Auth and a shared token are sent unencrypted). Use them only in a trusted LAN/VLAN, never expose the webhook port or the device to the internet, and keep the token secret.
• Biometric data / privacy (GDPR). Fingerprint templates, names, timestamps and access logs are personal data. You are the controller: obtain the consent of the people enrolled, protect backup files (fingerprints-backup.json contains the raw templates, unencrypted) and observe the laws that apply to you (e.g. GDPR/BDSG, works-council rules for employees).
• Actions run unattended. Fingerprint rules write to any ioBroker object you choose (lights, locks, alarms, scripts). Test your rules carefully before you depend on them.
• The authors are not liable for damage, loss of data, unauthorised access, burglary or any other consequence arising from the use or misuse of this software.

A German version is available in DISCLAIMER.de.md.

Security

Communication is authenticated in both directions:

• Adapter → device (status poll, reboot, touch ring): HTTP Basic Auth using the configured Admin User / Admin Password.
• Device → adapter (match/ring webhooks): a shared webhook token. The token is auto-generated on first start and shown in the instance settings. Requests without a valid token (via token query parameter or X-Auth-Token header) are rejected with HTTP 401. Optionally, enable "Accept webhooks only from the device IP" to also reject requests from any other host.

With firmware < v0.9.1 the token must be pasted manually into the device URLs. From v0.9.1 (server mode), the adapter provisions the URLs and token automatically.

adminPassword and webhookToken are declared as protected native attributes (protectedNative in io-package.json), so other adapters cannot read them. They are stored as plain text inside the instance configuration — encryption via encryptedNative is deliberately not used, because the webhook token is generated by the adapter itself.

Fingerprint Actions (no scripting)

The Fingerprint Actions tab lets you trigger ioBroker objects directly from a fingerprint — no JavaScript needed:

1. Click Load fingerprints from device to fill the table with the enrolled fingers (id + name). Existing rows are kept (merge).
2. For each row choose a Target object, an Action (Set value or Toggle), a Value and an optional Min confidence (leave empty to ignore).
3. The Value is freely typed and coerced to the target object's type:
   • boolean target: true, 1, on, yes, ja, да → true; anything else → false
   • number target: parsed as a number (, accepted as decimal separator)
   • string target: used as-is
4. Ring action sets a chosen object when an unknown finger rings (e.g. play a chime).

Smart rules (v0.5.0)

• Debounce (s) — ignore repeated triggers of the same finger within N seconds.
• Conditions checkbox — enforce time-based access windows for that finger. Define the windows on the Conditions tab: enter one or more finger IDs (comma-separated, e.g. 1,2,4), tick the weekdays and set a From/To time (HH:MM). Multiple rows for the same finger are OR-combined; time ranges may cross midnight (e.g. 22:00–06:00). If Conditions is on but no row matches, the action is skipped.
• Alarm checkbox (panic finger) — in addition to the normal action, sets the object configured under Alarm target. Example: a special finger opens the door as usual and also triggers an alarm state.
• Snapshot checkbox — in addition to the normal action, sets the object configured under Snapshot target. Example: trigger a script that captures an ESP32-CAM snapshot and sends it.

Manage Fingers (v0.6.0)

The Manage Fingers tab lets you administer fingers without opening the device WebUI:

• Rename — enter a finger ID and a new name, then click Rename.
• Create backup — downloads all fingerprint templates from the sensor and stores them in a file on the ioBroker host (<iobroker-data>/fingerprint.0/fingerprints-backup.json), which survives adapter updates.
• Restore from backup — writes the fingerprints from that file back to the sensor.

Save the instance settings first so the device connection is available.

Note: reliable backup/restore of all fingers needs firmware v0.9.4 (full 1536-byte templates). Backups made with older firmware are incomplete — re-create them after updating.

Enroll a new finger (v0.7.0, firmware ≥ v0.9.4)

You can enroll a new fingerprint directly from ioBroker — no need to open the device WebUI:

• Admin UI: Manage Fingers tab → Enroll a new finger → enter a free ID (1–200) and a name → Start enrollment.
• States: write control.enrollId and control.enrollName, then set control.enrollStart = true.

Enrollment runs on the device and needs the user to place the finger on the sensor 5 times. Progress is reported live in the enroll channel:

On success the fingerprint list is refreshed automatically.

LED ring control (v0.7.0, firmware ≥ v0.9.4)

Control the sensor's RGB ring from ioBroker:

• control.ledMode — 0 off, 1 on, 2 breathing, 3 flashing
• control.ledColor — 1 red, 2 blue, 3 purple, 4 green, 5 yellow, 6 cyan, 7 white

Writing either state applies the ring immediately.

States

Firmware note

• Match / Ring / Status / Reboot work with FingerprintDoorbell v0.9 as-is.
• control.ignoreTouchRing, server mode and the fingerprint list require v0.9.1.
• Backup / Restore of all fingers requires v0.9.3 (full 1536-byte templates).
• Enroll from adapter, LED ring, info.wifiRssi require v0.9.4.

Changelog

0.7.10

• Polling interval is range-checked (5–600 s) even if the config is edited outside the UI
• Removed unused translation keys; translated the localLinks name into all languages

0.7.9

• New: link to the device WebUI in the instance list of Admin (localLinks)

0.7.8

• README is English-only (German disclaimer moved to DISCLAIMER.de.md), added the 0.7.7 changelog entry, updated @iobroker/testing to 6.3.x

0.7.7

• Security/stability: errors in the async webhook handlers can no longer crash the adapter; objects are only created for valid finger IDs (1–200); constant-time token comparison; webhook timeouts; name length and device response size limits; LED values are range-checked; fixed an unhandled rejection after a failed backup request
• Added a disclaimer to the README
• Updated @iobroker/testing to 6.3.x

0.7.6

• HOTFIX for v0.7.5: declaring adminPassword / webhookToken as encryptedNative made the js-controller transform previously stored plain text values into unusable data before the adapter started, so the device login (HTTP Basic auth) and the server-mode provisioning failed. encryptedNative was removed again — the values are only declared as protectedNative now, so stored values keep working
• Unusable values are detected automatically: the webhook token is regenerated and the log asks to enter the admin password again (this also covers settings that were saved while v0.7.5 was active)
• New lib/secrets.js with unit tests for the secret repair logic

0.7.5

• Repository checker fixes: moved protectedNative / encryptedNative to the root of io-package.json (inside common they were ignored and the schema reported error E1105), reduced common.news to 7 entries, added the complete MIT license text including the copyright line to the README, completed the .vscode JSON schema settings, bumped @iobroker/testing to 6.2.x

0.7.4

• Repository review fixes: corrected state roles (control.enrollId/ledColor use level, ring.ringing uses sensor), marked adminPassword / webhookToken as protected & encrypted native, added Node.js 26 to CI, bumped @iobroker/testing to 6.x, added .vscode JSON schema settings

0.7.3

• Automated npm publishing via npm Trusted Publishing (OIDC) with provenance; removed the npm token from the deploy workflow

0.7.2

• Repository compliance for the ioBroker adapter repo: responsive size attributes in the admin UI, license copyright line, Ukrainian translations, a deploy workflow job, and internal cleanups (no functional change)

0.7.1

• The Enroll a new finger section (Manage Fingers) now also shows the Available fingers reference dropdown, so you can pick a free slot ID

0.7.0

• Enroll from the adapter (firmware ≥ v0.9.4): start enrollment from the Manage Fingers tab or via control.enrollStart; live progress in the enroll channel (active / step / status / message)
• LED ring control (firmware ≥ v0.9.4): control.ledMode + control.ledColor
• WiFi signal: new info.wifiRssi state (firmware ≥ v0.9.4)
• Conditions: added an Available fingers reference dropdown (id → name) so you know which IDs to enter

0.6.1

• Fix invalid jsonConfig: remove unsupported attr from the Manage Fingers rename fields (settings page failed to load)

0.6.0

• Manage Fingers tab: rename a finger, and backup / restore all fingerprints (stored in a file on the ioBroker host that survives adapter updates)
• Snapshot action: per-rule checkbox + a Snapshot target object — set in addition to the normal action, e.g. to trigger a script that captures an ESP32-CAM snapshot

0.5.1

• Conditions: the Finger field accepts several IDs comma-separated (e.g. 1,2,4); added a hint/tooltip

Older entries: see CHANGELOG_OLD.md
