iobroker.goodwe-pv

Versions

goodwe-pv adapter for ioBroker

Communication with GoodWe hybrid inverters of the ET, EH, BH and BT series via the local UDP interface (port 8899). No cloud connection required — the adapter talks directly to the inverter on your LAN.

Supported devices

All GoodWe hybrid inverters that expose the local Modbus-over-UDP interface on port 8899:

ET series (e.g. GW5-ET, GW8-ET, …)
EH series
BH series
BT series

Configuration

IP address — Local IP address of the GoodWe inverter (default: 127.0.0.1). Find it in your router's DHCP lease table or in the SEMS portal / ShinePhone app under "Device Info". A static IP or DHCP reservation is recommended.

Poll cycle — How often in seconds each data group is re-read from the inverter (default: 10). The four data groups (DeviceInfo, RunningData, ExtComData, BMSInfo) are staggered so only one UDP request is in flight per second.

Tip: Find the inverter's IP address in your router's DHCP lease table, or check the GoodWe SEMS portal / ShinePhone app under "Device Info". Assigning a static IP or DHCP reservation is recommended so the address does not change.

Based on

Donate

If you enjoyed this project — or just feeling generous, consider buying me a beer. Cheers! :beers:

Changelog

WORK IN PROGRESS

(hombach) updated dependencies

1.1.0 (2026-10-17)

(hombach) fixed repoChecker warnings
(hombach) updated dependencies
(hombach) fix 4-byte unsigned values with bit 31 set
(hombach) add battery mode as text (RunningData.Battery1.ModeText)
(hombach) fix EnergyDayDischarge (35211) read as 2 bytes
(hombach) add work mode as text (RunningData.WorkModeText)
(hombach) read BMS PackTemperature as signed value
(hombach) decode DiagStatusL bits into RunningData.DiagStatus
(hombach) read extended BMS info (37010-37014) and decode BMS error/warning bits

1.0.1 (2026-10-11)

(hombach) switch to iobroker testing 6.x
(hombach) added node 26 tests
(hombach) updated dependencies

1.0.0 (2026-09-06)

(hombach) version for stable release
(hombach) updated dependencies

0.2.4 (2026-08-07)

(hombach) add missing descriptions to DeviceInfo and BMSInfo states
(hombach) remove placeholder desc "-" from states without a meaningful description
(hombach) remove unused Rtc field from GoodWeRunningData type
(hombach) updated dependencies

0.2.3 (2026-07-18)

(hombach) replace deprecated role value.power.consumption with value.energy.consumed
(hombach) replace value.power.produced with value.energy.produced for accumulated kWh states
(hombach) replace invalid roles value.power.apparent and value.signal with valid alternatives
