ioBroker.mcp

Name: MCP Server
Author: ioBroker

MCP server for ioBroker

Description

This adapter exposes ioBroker as an MCP (Model Context Protocol) server, so MCP-capable clients (e.g. Claude Desktop) can read and control your installation through a well-defined set of tools.

Features

MCP server over the Streamable HTTP transport (/mcp endpoint)
Configurable HTTP/HTTPS web server
Configurable port and bind address
Optional authentication
Optional SSL/TLS support
Network diagnostics (ICMP ping / TCP probe) to troubleshoot adapter connections
Adapter repository search to recommend installable adapters

Operating modes

The adapter can run in two ways:

Standalone (default) – it starts its own web server on the configured port. The MCP endpoint is http(s)://<host>:<port>/mcp.
Web extension – it runs inside an existing web adapter instance and shares its web server (port, authentication, SSL). Select the target web instance in the admin configuration ("Extend WEB adapter"). The MCP endpoint is then served under the web adapter, e.g. http(s)://<host>:8082/mcp.

When a web instance is selected, the standalone server settings (port, bind address, authentication, SSL) are hidden because they are inherited from the chosen web instance.

Configuration

The adapter can be configured through the ioBroker admin interface using JSONConfig:

Server Configuration

Extend WEB adapter: Select a web instance to run as its extension. Leave empty to run standalone.
Port: The port on which the web server will listen (default: 8093) – standalone only
Bind Address: IP address to bind the server to (0.0.0.0 for all interfaces) – standalone only
MCP server URL: The address to enter in the MCP client, with a button to copy it. Standalone it is built from SSL, bind address and port of this instance; as a web extension from SSL, bind address and port of the selected web instance (with "all instances" one URL per instance). With OAuth and a Public URL the public URL is used, otherwise the host from the address of the admin page.

Authentication

Enable Authentication: Enable ioBroker user authentication for the web server
Default User: The ioBroker user whose permissions MCP requests run with when authentication is off (default: admin). With authentication on, every session runs with the permissions of the user who logged in, so this field is hidden then. All object/state reads and writes performed by the tools are executed in the name of that user, so the user's ACLs are enforced. A plain name like operator is automatically expanded to system.user.operator. As a web extension the authentication and the default user of the web instance apply.

OAuth

MCP clients such as Claude Desktop connect through a browser login instead of a token you create by hand. The client discovers the server on its own, the user logs in and confirms, and the client never sees the ioBroker password.

Enable OAuth (browser login): In standalone mode this requires Enable Authentication. As a web extension the selected web instance provides the login, so OAuth has to be enabled there as well ("Allow third-party clients") — otherwise MCP clients only receive a redirect to the login page, which they cannot use.
Public URL: The externally reachable address of this server, without a path, e.g. https://iobroker.example.com. Required behind a reverse proxy: the URLs published for OAuth discovery must be the ones the client can actually reach. As a web extension it must match the public URL configured in the web instance.
Allow client self-registration: Let MCP clients register themselves (default: on). With this off, every client has to be registered by hand first. In web-extension mode this is the web instance's setting, so the option is hidden here.

HTTPS is required for anything but localhost — the flow runs through the user's browser, and MCP clients refuse plain http:// for remote hosts.

Access tokens are bound to this endpoint, so a token issued for another service on the same server is rejected. Clients can drop their tokens again via POST /oauth/revoke.

Permissions

All options that change the system are off by default; turn on only what the MCP client really needs.

States and objects

Allow setting states: Allow MCP clients to write state values and to acknowledge system notifications (the set_state, set_states and clear_notifications tools). Default: on. Which states can be written is decided by the ACLs of the user the request runs with (logged-in user or Default User). set_states checks the write permission of all states first and writes nothing if one of them is not writable.
Mark setting states as destructive (setStateDestructive): Declare set_state and set_states with destructiveHint: true, so MCP clients can warn before a state is written. Default: on. When off, both tools are declared as non-destructive writes (readOnlyHint stays false); whether a client still asks for confirmation then depends on the client.
Allow object/file changes (allowObjectChange): Allow MCP clients to create/modify/delete objects, aliases and files (the set_object, delete_object, create_state, create_scene, create_alias, write_file, delete_file, rename_file and mkdir tools). Default: off.

System

Allow controlling instances (allowInstanceControl): Start, stop and restart adapter instances and change their log level (start_instance, stop_instance, restart_instance, set_log_level). Default: off.
Allow managing adapters (allowAdapterManagement): Add and delete instances and upgrade adapters from the repository (add_instance, delete_instance, upgrade_adapter). Default: off.
Allow changing scripts (allowScriptChange): Create, change, start/stop and delete scripts of the javascript adapter and run code once (set_script, enable_script, delete_script, run_script). Reading scripts (list_scripts, get_script) is always possible. Scripts run with full access to ioBroker. Default: off.
Allow messages to adapters (sendToAllowlist): Adapters (telegram) or instances (backitup.0) the send_to tool may send messages to, separated by commas; * allows all. Default: empty, then there is no send_to tool.

Safety

Ask for confirmation before dangerous actions (confirmDangerous): MCP clients that support elicitation ask the user before an object or instance is deleted, an instance stopped, an adapter upgraded or installed, a script saved or run, or a message sent. Clients without elicitation rely on the destructiveHint of the tools and their own confirmation. Default: on.
Allow download/upload links (transferLinks): Tools may hand out short-lived links for data that is too large for an MCP message, see Large results and files. Default: on.

Developers

Allow installing packages (developers only) (allowPackageInstall): Offer the install_package tool, which installs an adapter package on an ioBroker host - from npm, GitHub, a URL or a .tgz file - exactly like Install from custom URL / file in ioBroker.admin (iobroker url ...). Default: off. This option is only relevant for adapter developers, e.g. to let an AI agent build an adapter, pack it with npm pack and install the .tgz on a test system. An installed package runs with full rights on the host, so never enable it on a productive system or for clients you do not fully trust.

Rights of the ioBroker user The options above decide which tools exist; what a call may do is decided by the rights of the ioBroker user the MCP session runs as (the logged-in user, or the Default User without authentication), like in ioBroker.admin:

the ACLs of objects, states and files for reading and writing them,
the "other" rights of the user's groups: execute for commands on a host (install_package, add_instance, delete_instance, upgrade_adapter) and sendto for messages to adapters (send_to, run_script). Without them the call is refused before anything runs. Administrators have all rights.

A session is not even offered the tools that need a right the groups of its user lack: without the write right for states no set_state/set_states, without the write right for objects no set_object, create_state, start_instance, ..., without the delete right for states no delete_orphan_states, without the write right for files no write_file, without execute no install_package, without sendto no send_to. The rights are read when the session starts; every call is checked anyway.

check_permissions shows these rights and the ACLs of given objects.

Log Every call of a changing tool is logged at info level with the user, the tool and its arguments (MCP system.user.admin: set_state(id="hue.0.light.state", value=true)), and every failed call as a warning with the same details. Long values are shortened; file contents, script code and send_to payloads are replaced by their size.

SSL/TLS Configuration

Enable HTTPS: Enable HTTPS/SSL for secure connections
Public Certificate: Path to the public certificate file
Private Key: Path to the private key file
Chained Certificate: Path to the chained certificate file (optional)

Connecting ChatGPT and Claude

There is no official ioBroker app in the connector directories of Claude and ChatGPT yet. Until then, add ioBroker as a custom connector. There are two ways to reach your installation:

	A: via ioBroker Remote (recommended)	B: directly to your server
Server URL	`https://mcp.iobroker.in/mcp`	`https://<your public address>/mcp`
Login	e-mail and password of your ioBroker.pro account	ioBroker user of your installation
Requirements	ioBroker.pro account and assistance or remote active subscription	public HTTPS address (port forwarding or reverse proxy)
Open ports	none	your MCP or web port must be reachable from the internet

A: via ioBroker Remote

Configure this adapter (standalone or as web extension). Leave Enable Authentication and Enable OAuth off: the login happens on iobroker.pro, and ioBroker.iot connects to this instance locally without credentials. As a web extension, the selected web instance must not use authentication either. The port does not have to be reachable from the internet.
In the settings of ioBroker.iot (logged in with your ioBroker.pro account) enable Allow remote access and select this instance as MCP instance. Save.
Add the connector in Claude or ChatGPT (see below) with the URL https://mcp.iobroker.in/mcp.
A login page "Connect to ioBroker" opens: enter the e-mail and password of your ioBroker.pro account and click Sign in and allow. Only allow the connection if you have just set it up yourself.

Access is granted with a verified e-mail address and a valid ioBroker.pro license. New accounts can use it for 7 days after the registration without a license.

Good to know:

ioBroker.iot must be connected to the cloud, otherwise the client gets the error "ioBroker is offline".
Live updates (subscribing to resources) are not available via Remote. All tools work.
After a restart of the MCP instance, the client starts a new session by itself.
Removing the connector in the client ends the access. An already issued access token stays valid for up to one hour. To stop the access immediately, clear MCP instance in ioBroker.iot.

B: directly to your server

Enable Enable Authentication and Enable OAuth. As a web extension, enable OAuth ("Allow third-party clients") in the web instance as well.
Make the server reachable via HTTPS from the internet and enter this address as Public URL.
Use the URL https://<your public address>/mcp in the client and log in with an ioBroker user.

Claude (claude.ai, Claude Desktop)

Custom connectors are available on all plans, the Free plan is limited to one custom connector.

Open Customize → Connectors, click + and select Add custom connector.
Enter a name (e.g. ioBroker) and the server URL. The Advanced settings (OAuth client ID and secret) stay empty, Claude registers itself.
Click Add. If the login does not start by itself, click Connect next to the connector.
In a chat, click + (lower left) → Connectors and enable ioBroker.

Team and Enterprise: an owner first adds the connector under Organization settings → Connectors → Add → Custom → Web. Members then open Customize → Connectors and click Connect.

Claude Code:

claude mcp add --transport http iobroker https://mcp.iobroker.in/mcp

Then run /mcp in Claude Code, select iobroker and log in in the browser.

ChatGPT

Custom MCP connections need the developer mode, which is available for Plus, Pro, Business, Enterprise and Education accounts in ChatGPT on the web. In Business and Enterprise workspaces an admin has to allow it first.

Open Settings → Security and login and turn on Developer mode.
Open ChatGPT Plugins and click +.
Enter a name (e.g. ioBroker) and a description (e.g. "Reads and controls my ioBroker smart home"). Under Connection choose Public endpoint and enter the server URL. Choose OAuth as authentication.
Create the connection and log in. ChatGPT then lists the tools of ioBroker.
In a chat, open + → Developer mode and select ioBroker. It helps to name ioBroker explicitly in the request, e.g. "Use ioBroker to switch off the lights in the kitchen".

ChatGPT marks developer mode connections as elevated risk and asks before write actions.

The menu names are taken from the help pages of Claude and ChatGPT (September 2026) and may change.

Recommendations

Let the AI log in with an ioBroker user that has only the rights it should have, or, without authentication, set such a user as Default User. Every tool runs with its permissions.
Leave Allow object/file changes off unless you need it.
Turn on the System options (instances, adapters, scripts, messages) only for clients you trust, and only the ones you need. With Allow messages to adapters name the adapters explicitly instead of *.
Leave Allow installing packages off. It is only meant for adapter developers on test systems.
Leave Mark setting states as destructive and Ask for confirmation before dangerous actions on, so the clients ask before they switch or change something.

MCP Endpoint

The MCP server is served at POST/GET/DELETE /mcp using the Streamable HTTP transport with per-session state (tracked via the Mcp-Session-Id header). Point your MCP client at:

standalone: http(s)://<host>:<port>/mcp
web extension: http(s)://<host>:<webPort>/mcp

Available tools

Tool	Description
`get_states`	Retrieve the current value of one or multiple states; IDs may contain wildcards (e.g. `hue.0.*.brightness`); an ID without a state is returned with `exists: false` or a hint
`wait_for_state`	Wait until a state has a `value` (or, without `value`, until it is updated), optionally only with `ack`; gives up after `timeout` seconds (default 30, at most 50) with `reached: false`
`find_orphan_states`	Find states without object (e.g. `system.adapter.vis.0.alive` of a deleted instance) by an ID `pattern`, except the upload progress `system.adapter.<adapter>.upload`, which has no object on purpose; delete them with `delete_orphan_states` or on the host with `iobroker state del <id>`
`get_object`	Read a single object by its ID
`check_permissions`	Show the user and groups of the MCP session, the rights of its groups and, for given object IDs, whether it may read/write/delete the object and read/write the state
`search_objects`	Search objects/states by keyword (matched against ID and name); optional filters for object `type`, `role`, `room` and source `adapter` instance
`list_devices`	List detected devices grouped by room (uses the ioBroker type-detector to expose functional devices with named controls); optional `language` and `room` filter
`list_instances`	List adapter instances with their status
`list_adapters`	List installed adapters with metadata (version, title, description, keywords)
`search_adapter_repository`	Search the ioBroker adapter repository (all installable adapters, not just installed ones) by keyword; optional `type` category, `onlyNotInstalled` and `language` filters — use it to recommend which adapter to install for a device/service
`list_hosts`	List ioBroker hosts with their status
`list_rooms`	List rooms (`enum.rooms.*`) with localized names and member details; optional `language` and `withIcons`
`list_functions`	List functions (`enum.functions.*`) with localized names and member details; optional `language` and `withIcons`
`history_query`	Query historical values (requires a history adapter); aggregations: `raw`, `min`, `max`, `avg`, `sum`, `count`, `minmax`, `percentile`, `quantile`, `integral`
`read_file`	Read a file from an adapter file storage (optional base64); large files in chunks via `offset`/`length`; `download: true` returns a download link instead
`list_files`	List a directory in an adapter file storage
`file_exists`	Check whether a file exists in an adapter file storage
`get_logs`	Retrieve recent ioBroker log lines; optional filters by `level` (error/warn/info/debug), source `adapter`, start time (`from_ts`) and `search` in the message (text, or `/regex/flags`); `logFile` tells the time of the newest line and the file size
`write_log`	Write a message to the ioBroker log
`system_info`	Get system and js-controller information
`list_adapter_updates`	List installed adapters that have a newer version in the active repository
`list_notifications`	List the system notifications of the hosts (the bell in admin): disk space, crashed adapters, ...
`list_scripts`	List the scripts of the javascript adapter (without source)
`get_script`	Read a script including its source
`ping_host`	Diagnose connectivity to a network device: ICMP ping to `host` plus an optional TCP connect to `port` — useful to investigate adapter `ETIMEDOUT`/connection errors
`set_state`	Set the value of a state (value coerced to the state type); with `wait_ack` (seconds) it waits until the device confirms the command (`ack: true`) and returns the confirmed state — requires Allow setting states
`set_states`	Set multiple states in one call (for scenes/group actions like "all lights off") — requires Allow setting states
`clear_notifications`	Acknowledge system notifications, optionally of one scope/category/instance — requires Allow setting states
`set_object`	Create/update an object (merges common/native) — requires Allow object/file changes
`delete_object`	Delete an object, optionally with all children — requires Allow object/file changes
`delete_orphan_states`	Delete states without object, given by their IDs or by patterns like `system.adapter.vis.0.`; each state is checked again first, so a state with an object and the upload progress of an adapter are never deleted — requires Allow object/file changes*
`create_state`	Create a new state object with type/role/unit/min/max and optional initial value — requires Allow object/file changes
`create_scene`	Create or update a scene for the ioBroker `scenes` adapter (state/value pairs applied together) — requires Allow object/file changes
`create_alias`	Create an alias (`alias.0.`) pointing to a state, optionally with a separate write state — requires Allow object/file changes*
`write_file`	Write a file to an adapter file storage, from `content` or from a file uploaded via `prepare_upload` (`upload_id`) — requires Allow object/file changes
`delete_file`	Delete a file from an adapter file storage — requires Allow object/file changes
`rename_file`	Rename/move a file within the same adapter file storage — requires Allow object/file changes
`mkdir`	Create a directory in an adapter file storage — requires Allow object/file changes
`prepare_upload`	Get a one-time upload link for a file that is too large for a tool argument (e.g. a `.tgz`), for clients that can run shell commands — requires Allow download/upload links and Allow object/file changes or Allow installing packages
`install_package`	Install an adapter package (npm, GitHub, URL, `.tgz` from the file storage, as base64 or uploaded via `prepare_upload`) on a host, restart its enabled instances and report whether they came up, with their first log lines — requires Allow installing packages, developers only
`start_instance`	Start (enable) an instance — requires Allow controlling instances
`stop_instance`	Stop (disable) an instance — requires Allow controlling instances
`restart_instance`	Restart a running instance — requires Allow controlling instances
`set_log_level`	Change the log level of an instance, temporarily or persistently — requires Allow controlling instances
`add_instance`	Create an instance of an adapter from the repository (`iobroker add`) — requires Allow managing adapters
`delete_instance`	Delete an instance with its objects and states (`iobroker del`) — requires Allow managing adapters
`upgrade_adapter`	Upgrade an adapter to the repository or a given version (`iobroker upgrade`) — requires Allow managing adapters
`set_script`	Create a JavaScript/TypeScript script or change its source — requires Allow changing scripts
`enable_script`	Start or stop a script — requires Allow changing scripts
`delete_script`	Delete a script — requires Allow changing scripts
`run_script`	Run code once in the javascript adapter and return its log output (javascript ≥ 10.1.0) — requires Allow changing scripts
`send_to`	Send a message to an adapter instance (`sendTo`) and return the answer — only instances in Allow messages to adapters

All object/state access runs with the permissions of the logged-in user, or of the Default User without authentication. The write tools are only registered when their respective permission option is enabled, and only offered to users whose groups have the rights they need.

Large results and files

MCP clients reject tool results above 1 MiB, and a model cannot pass megabytes of base64 as a tool argument. So:

Every result stays below the limit. Lists (get_states, search_objects, list_files, list_scripts, history_query) return as many entries as fit and add truncated, total, nextOffset and a hint; call again with offset set to nextOffset for the next part. get_logs keeps the newest lines. Any other result that is too large is replaced by a download link, or by an error asking to narrow the request down.
Download links (download_url): a cut list carries a link to all of its entries as JSON, and read_file with download: true returns a link to the whole file. Clients that can run shell commands (e.g. Claude Code) fetch it with curl -o <file> "<download_url>".
Upload links: prepare_upload returns a link and an upload_id. The client uploads the file with curl -T <file> "<url>" (PUT or POST, raw body, up to 100 MB) and passes the upload_id to write_file or install_package. A link can be used once. This way an AI agent can install a .tgz it built with npm pack.

The links are <mcp endpoint>/transfer/<token>: the random token is the credential, so they work without the login of the MCP endpoint, and they expire after 15 minutes. They are not available as a web extension with authentication enabled in the web adapter, because the web adapter asks for a login first; the tools then say so.

Prompts

MCP clients offer these as ready-made commands (e.g. as slash commands):

diagnose_adapter (instance) - find out why an instance does not work: status, log, notifications, connectivity and available updates.
room_overview (room) - summary of the devices of a room and anything unusual.
create_automation (description) - turn a description into a script for the javascript adapter.

Resources & live updates (SSE)

States and objects are also exposed as MCP resources using the canonical ioBroker URI scheme, so clients can read and subscribe to them. The server pushes changes over the Streamable HTTP SSE stream (notifications/resources/updated).

States: iobstate://<id> (e.g. iobstate://javascript.0.temperature) – resources/read returns { id, val, ack, ts, lc, q }.
Objects: iobobject://<id> (e.g. iobobject://system.adapter.admin.0) – resources/read returns the object.
Logs: ioblog://all (every source) or ioblog://<source> (e.g. ioblog://admin.0) – resources/read returns the recent log lines ({ source, logs: [{ ts, level, source, message }] }). Subscribing enables log forwarding for the adapter; each new matching line triggers a notifications/resources/updated.
resources/subscribe subscribes to the underlying ioBroker state/object/log; on every change the client receives a notifications/resources/updated for that URI and re-reads it. resources/unsubscribe stops it.

Subscriptions are tracked per session and ref-counted, so the adapter subscribes to a state/object only once regardless of how many clients/sessions watch it, and unsubscribes when the last one leaves.

(Files use iobfile://<adapter>/<path> in the same scheme; they are available via the read_file/write_file tools rather than as subscribable resources.)

Health endpoints (non-MCP)

GET / - Basic server information
GET /status - Server status, uptime and active session count
GET /api/info - Adapter information

Changelog

1.8.1 (2026-10-27)

(@GermanBluefox) Fixed: js-controller usually killed the instance with SIGKILL when stopping it, because the adapter never closed its server and the connections of the MCP clients

1.8.0 (2026-10-27)

(@GermanBluefox) New tool delete_orphan_states: deletes the states without object found by find_orphan_states, but never a state with an object (@iobroker/mcp-server 1.9.0)

1.7.1 (2026-10-26)

(@GermanBluefox) find_orphan_states no longer reports the upload progress of the adapters (system.adapter.<adapter>.upload), which js-controller writes without object on purpose (@iobroker/mcp-server 1.8.1)

1.7.0 (2026-10-26)

(@GermanBluefox) Security: commands on a host need the "execute" right of the user, messages to adapters the "sendto" right, like in admin; a session is only offered the tools its user has the rights for (@iobroker/mcp-server 1.8.0)
(@GermanBluefox) Every change made via MCP is logged with the user, the tool and its arguments; get_logs searches the messages for a text or a regular expression (@iobroker/mcp-server 1.8.0)
(@GermanBluefox) set_state can wait for the confirmation of the device (wait_ack); new tools wait_for_state and find_orphan_states (@iobroker/mcp-server 1.8.0)
(@GermanBluefox) install_package reports a done installation even if the instances could not be restarted afterwards (@iobroker/mcp-server 1.8.0)

1.6.2 (2026-10-26)

(@GermanBluefox) Fixed: get_logs always returned size: null for the log file (@iobroker/mcp-server 1.7.1)

License

MIT License

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
